1MRK 504 135-UEN A
12.9.4
Table 262: I103CMD Non group settings (basic)
Name Values (Range)
FunctionType
12.10
12.10.1
12.10.2
12.10.3
Technical manual

Settings

Unit
1 - 255 -

IED commands for IEC 60870-5-103 I103IEDCMD

Functionality

I103IEDCMD is a command block in control direction with defined IED functions.
All outputs are pulsed and they are NOT stored. Pulse length is fixed to 400ms.

Function block

I103IEDCMD
BLOCK 19-LEDRS
IEC10000283-1-en.vsd
IEC10000283 V1 EN
Figure 159: I103IEDCMD function block

Signals

Table 263: I103IEDCMD Input signals
Name
BLOCK
Table 264: I103IEDCMD Output signals
Name
19-LEDRS
23-GRP1
24-GRP2
25-GRP3
26-GRP4
Step Default
1 1
23-GRP1
24-GRP2
25-GRP3
26-GRP4
Type Default Description
BOOLEAN 0
Type Description
BOOLEAN
BOOLEAN
BOOLEAN
BOOLEAN
BOOLEAN
Description
Function type (1-255)
Block of commands
Information number 19, reset LEDs
Information number 23, activate setting group 1
Information number 24, activate setting group 2
Information number 25, activate setting group 3
Information number 26, activate setting group 4
Section 12
Control
365
