Technical manual
chronological order in which the IED should be commissioned. The relevant
procedures may be followed also during the service and maintenance activities.
The operation manual contains instructions on how to operate the IED once it has been
commissioned. The manual provides instructions for the monitoring, controlling and
setting of the IED. The manual also describes how to identify disturbances and how to
view calculated and measured power grid data to determine the cause of a fault.
The application manual contains application descriptions and setting guidelines
sorted per function. The manual can be used to find out when and for what purpose a
typical protection function can be used. The manual can also provides assistance for
calculating settings.
The technical manual contains application and functionality descriptions and lists
function blocks, logic diagrams, input and output signals, setting parameters and
technical data, sorted per function. The manual can be used as a technical reference
during the engineering phase, installation and commissioning phase, and during
normal service.
The communication protocol manual describes the communication protocols
supported by the IED. The manual concentrates on the vendor-specific
implementations.
The point list manual describes the outlook and properties of the data points specific
to the IED. The manual should be used in conjunction with the corresponding
communication protocol manual.

Document revision history

Document revision/date
-/March 2013
A/October 2016

Related documents

Documents related to RET650
Application manual
Technical manual
Commissioning manual
Product Guide, configured
Type test certificate
Application notes for Circuit Breaker Control
650 series manuals
Communication protocol manual, DNP 3.0
Communication protocol manual, IEC 61850–8–1
Communication protocol manual, IEC 60870-5-103
Table continues on next page
History
First release
Minor corrections made
Section 1
Introduction
Identity number
1MRK 504 134-UEN
1MRK 504 135-UEN
1MRK 504 136-UEN
1MRK 504 137-BEN
1MRK 504 137-TEN
1MRG006806
Identity number
1MRK 511 280-UEN
1MRK 511 281-UEN
1MRK 511 282-UEN
31
