1MRK 504 135-UEN A
12.1.4.2
Table 186: SXSWI Non group settings (basic)
Name Values (Range)
tStartMove
tIntermediate
AdaptivePulse
tOpenPulse
tClosePulse
SwitchType
SuppressMidPos
Technical manual
Name
BL_CLOSE
BL_UPD
POSOPEN
POSCLOSE
TR_OPEN
TR_CLOSE
RS_CNT
XIN
Table 185: SXSWI Output signals
Name
XPOS
EXE_OP
EXE_CL
OP_BLKD
CL_BLKD
UPD_BLKD
POSITION
OPENPOS
CLOSEPOS
TR_POS
CNT_VAL
L_CAUSE

Settings

Unit
0.000 - 60.000 s
0.000 - 60.000 s
Not adaptive -
Adaptive
0.000 - 60.000 s
0.000 - 60.000 s
Load Break -
Disconnector
Earthing Switch
HS Earthing Switch
Off -
On
Type Default Description
BOOLEAN 0 Signal to block the close command
BOOLEAN 0 Steady signal for block of the position updating
BOOLEAN 0 Signal for open position of apparatus from I/O
BOOLEAN 0 Signal for close position of apparatus from I/O
BOOLEAN 0 Signal for open position of truck from I/O
BOOLEAN 0 Signal for close position of truck from I/O
BOOLEAN 0 Resets the operation counter
BOOLEAN 0 Execution information from CSWI
Type Description
GROUP SIGNAL Group connection to CSWI
BOOLEAN Executes the command for open direction
BOOLEAN Executes the command for close direction
BOOLEAN Indication that the function is blocked for open
commands
BOOLEAN Indication that the function is blocked for close
commands
BOOLEAN Update of position indication is blocked
INTEGER Apparatus position indication
BOOLEAN Apparatus open position
BOOLEAN Apparatus closed position
INTEGER Truck position indication
INTEGER Operation counter value
INTEGER Latest value of the error indication during command
Step Default
0.001 3.000
0.001 15.000
- Not adaptive
0.001 0.200
0.001 0.200
- Disconnector
- On
Section 12
Description
Supervision time for the apparatus to
move after a command
Allowed time for intermediate position
Output resets when a new correct end
position is reached
Output pulse length for open command
Output pulse length for close command
1=LoadBreak,2=Disconnector,
3=EarthSw,4=HighSpeedEarthSw
Mid-position is suppressed during the
time tIntermediate
Control
261
