Monitored data

Table 115: GOPPDOP Monitored data
Name Type
P REAL
PPERCENT REAL
Q REAL
QPERCENT REAL

Directional underpower protection GUPPDUP

Identification

Function description
Directional underpower protection

Function block

GUPPDUP
I3P* TRIP
U3P* TRIP1
BLOCK TRIP2
BLKST1 START
BLKST2 START1
START2
PPERCENT
Q
QPERCENT
IEC08000507-2-en.vsd
IEC08000507 V2 EN
Figure 87: GUPPDUP function block
Values (Range)
-
-
-
-
IEC 61850
identification
GUPPDUP
P
1MRK 504 135-UEN A
Unit Description
MW Active Power
% Active power in % of
calculated power base
value
MVAr Reactive power
% Reactive power in % of
calculated power base
value
IEC 60617 ANSI/IEEE C37.2
identification device number
37
P <
2
SYMBOL-LL V2 EN
