Section 12
Control
12.1.3.2
Table 183: SXCBR Non group settings (basic)
Name
tStartMove
tIntermediate
AdaptivePulse
tOpenPulse
tClosePulse
SuppressMidPos
12.1.4
12.1.4.1
260
Table 182: SXCBR Output signals
Name
XPOS
EXE_OP
EXE_CL
OP_BLKD
CL_BLKD
UPD_BLKD
POSITION
OPENPOS
CLOSEPOS
TR_POS
CNT_VAL
L_CAUSE

Settings

Values (Range) Unit
0.000 - 60.000 s
0.000 - 60.000 s
Not adaptive -
Adaptive
0.000 - 60.000 s
0.000 - 60.000 s
Off -
On

Circuit switch SXSWI

Signals

Table 184: SXSWI Input signals
Name
BLOCK
LR_SWI
OPEN
CLOSE
BL_OPEN
Table continues on next page
Type Description
GROUP SIGNAL Group connection to CSWI
BOOLEAN Executes the command for open direction
BOOLEAN Executes the command for close direction
BOOLEAN Indication that the function is blocked for open
commands
BOOLEAN Indication that the function is blocked for close
commands
BOOLEAN Update of position indication is blocked
INTEGER Apparatus position indication
BOOLEAN Apparatus open position
BOOLEAN Apparatus closed position
INTEGER Truck position indication
INTEGER Operation counter value
INTEGER Latest value of the error indication during command
Step Default
0.001 0.100
0.001 0.150
- Not adaptive
0.001 0.200
0.001 0.200
- On
Type Default Description
BOOLEAN 0 Block of function
BOOLEAN 0 Local/Remote switch indication from switchyard
BOOLEAN 0 Pulsed signal used to immediately open the switch
BOOLEAN 0 Pulsed signal used to immediately close the switch
BOOLEAN 0 Signal to block the open command
1MRK 504 135-UEN A
Description
Supervision time for the apparatus to
move after a command
Allowed time for intermediate position
Output resets when a new correct end
position is reached
Output pulse length for open command
Output pulse length for close command
Mid-position is suppressed during the
time tIntermediate
