Settings; Operation Principle; Goose Function Block To Receive A Measurand Value Goosemvrcv; Identification - ABB RET650 Technical Manual

Section 16
Station communication
16.8.5
Table 459: GOOSEINTRCV Non group settings (basic)
Name
Operation
16.8.6
16.9
16.9.1
546
Table 458: GOOSEINTRCV Output signals
Name
INTOUT
DATAVALID
COMMVALID
TEST

Settings

Values (Range) Unit
Off -
On

Operation principle

The DATAVALID output will be HIGH if the incoming message is with valid data.
The COMMVALID output will become LOW when the sending IED is under total
failure condition and the GOOSE transmission from the sending IED does not happen.
The TEST output will go HIGH if the sending IED is in test mode.
The input of this GOOSE block must be linked in SMT by means of
a cross to receive the integer values.
The implementation for IEC61850 quality data handling is restricted
to a simple level. If quality data validity is GOOD then the
DATAVALID output will be HIGH. If quality data validity is
INVALID, QUESTIONABLE, OVERFLOW, FAILURE or OLD
DATA then the DATAVALID output will be LOW.
GOOSE function block to receive a measurand value
GOOSEMVRCV

Identification

Function description
GOOSE function block to receive a
measurand value
Type Description
INTEGER Integer output
BOOLEAN Data valid for integer output
BOOLEAN Communication valid for integer output
BOOLEAN Test output
Step Default
- Off
IEC 61850
identification
GOOSEMVRCV
1MRK 504 135-UEN A
Description
Operation Off/On
IEC 60617 ANSI/IEEE C37.2
identification device number
- -
Technical manual
