Name Type
HMICTR6 INTEGER
HMICTR7 INTEGER
HMICTR8 INTEGER
HMICTR9 INTEGER
HMICTR10 INTEGER
HMICTR11 INTEGER
HMICTR12 INTEGER

Settings

The function does not have any parameters available in Local HMI or Protection and
Control IED Manager (PCM600).

Select release SELGGIO

Identification

Function description
Select release

Function block

SELGGIO
SELECT1 RESERVED
SELECT2
SELECT3
SELECT4
SELECT5
SELECT6
SELECT7
SELECT8
SELECT9
SELECT10
SELECT11
SELECT12
SELECT13
SELECT14
SELECT15
SELECT16
IEC09000084_1_en.vsd
IEC09000084 V1 EN
Figure 121: SELGGIO function block

Signals

Table 195: SELGGIO Input signals
Name Type
SELECT1 BOOLEAN
SELECT2 BOOLEAN
SELECT3 BOOLEAN
Table continues on next page
Description
Bitmask output 6 to local remote LHMI input
Bitmask output 7 to local remote LHMI input
Bitmask output 8 to local remote LHMI input
Bitmask output 9 to local remote LHMI input
Bitmask output 10 to local remote LHMI input
Bitmask output 11 to local remote LHMI input
Bitmask output 12 to local remote LHMI input
IEC 61850 IEC 60617
identification identification
SELGGIO -
Default Description
0 Select signal of control 1
0 Select signal of control 2
0 Select signal of control 3
