Settings - ABB RET650 Technical Manual

1MRK 504 135-UEN A
14.4.5.4
Table 378: B1RBDR Non group settings (basic)
Name Values (Range)
TrigDR01
SetLED01
TrigDR02
Table continues on next page
Technical manual
Table 377: B1RBDR Input signals
Name
INPUT1
INPUT2
INPUT3
INPUT4
INPUT5
INPUT6
INPUT7
INPUT8
INPUT9
INPUT10
INPUT11
INPUT12
INPUT13
INPUT14
INPUT15
INPUT16

Settings

B1RBDR - B6RBDR Settings
Setting tables for B1RBDR - B6RBDR are all similar except for binary channel and
description numbers.
• B1RBDR, channel1 - channel16
• B2RBDR, channel17 - channel32
• B3RBDR, channel33 - channel48
• B4RBDR, channel49 - channel64
• B5RBDR, channel65 - channel80
• B6RBDR, channel81 - channel96
Unit
Off -
On
Off -
Start
Trip
Start and Trip
Off -
On
Type Default Description
BOOLEAN 0 Binary channel 1
BOOLEAN 0 Binary channel 2
BOOLEAN 0 Binary channel 3
BOOLEAN 0 Binary channel 4
BOOLEAN 0 Binary channel 5
BOOLEAN 0 Binary channel 6
BOOLEAN 0 Binary channel 7
BOOLEAN 0 Binary channel 8
BOOLEAN 0 Binary channel 9
BOOLEAN 0 Binary channel 10
BOOLEAN 0 Binary channel 11
BOOLEAN 0 Binary channel 12
BOOLEAN 0 Binary channel 13
BOOLEAN 0 Binary channel 14
BOOLEAN 0 Binary channel 15
BOOLEAN 0 Binary channel 16
Step Default
- Off
- Off
- Off
Section 14
Monitoring
Description
Trigger operation On/Off
Set LED on HMI for binary channel 1
Trigger operation On/Off
461
