Section 13
Logic
13.9.2
13.9.3
13.9.4
404

Functionality

Elapsed Time Integrator (TEIGGIO) function is a function that accumulates the
elapsed time when a given binary signal has been high.
The main features of TEIGGIO are
• Applicable to long time integration (≤999 999.9 seconds).
• Supervision of limit transgression conditions and overflow.
• Possibility defining a warning or alarm with the resolution of 10 milliseconds.
• Retain the integration value at a warning/alarm/overflow.
• Possibilities for blocking and reset.
• Report the integrated time

Function block

TEIGGIO
BLOCK WARNING
IN ALARM
RESET OVERFLOW
ACCTIME
IEC13000005-1-en.vsd
IEC13000005 V1 EN
Figure 183: TEIGGIO function block

Signals

Table 323: TEIGGIO Input signals
Name Type
BLOCK BOOLEAN
IN BOOLEAN
RESET BOOLEAN
Table 324: TEIGGIO Output signals
Name Type
WARNING BOOLEAN
ALARM BOOLEAN
OVERFLOW BOOLEAN
ACCTIME REAL
Default Description
0 Freeze the integration and block the other outputs
0 The input signal that is used to measure the
elapsed time, when its value is high
0 Reset the integration time
Description
Indicator of the integrated time has reached the
warning limit
Indicator of the integrated time has reached the
alarm limit
Indicator of the integrated time has reached the
overflow limit
Integrated elapsed time in seconds
1MRK 504 135-UEN A
Technical manual
