Settings; Interlocking For 1 1/2 Cb Bh; Identification - ABB RET650 Technical Manual

1MRK 504 135-UEN A
12.2.4.6
12.2.5
12.2.5.1
Technical manual
Name Type
BC12OPTR BOOLEAN
BC12CLTR BOOLEAN
BC17OPTR BOOLEAN
BC17CLTR BOOLEAN
BC27OPTR BOOLEAN
BC27CLTR BOOLEAN
VPQB1TR BOOLEAN
VQB220TR BOOLEAN
VPQB7TR BOOLEAN
VPQB12TR BOOLEAN
VPBC12TR BOOLEAN
VPBC17TR BOOLEAN
VPBC27TR BOOLEAN

Settings

The function does not have any settings available in Local HMI or Protection and
Control IED Manager (PCM600).

Interlocking for 1 1/2 CB BH

Identification

Function description
Interlocking for 1 1/2 breaker diameter
Interlocking for 1 1/2 breaker diameter
Interlocking for 1 1/2 breaker diameter
Description
No connection via the own bus coupler between
WA1 and WA2
Connection exists via the own bus coupler between
WA1 and WA2
No connection via the own bus coupler between
WA1 and WA7
Connection exists via the own bus coupler between
WA1 and WA7
No connection via the own bus coupler between
WA2 and WA7
Connection exists via the own bus coupler between
WA2 and WA7
Switch status of QB1 is valid (open or closed)
Switch status of QB2 and QB20 are valid (open or
closed)
Switch status of QB7 is valid (open or closed)
Switch status of QB1 and QB2 are valid (open or
closed)
Status of the bus coupler apparatuses between
WA1 and WA2 are valid
Status of the bus coupler apparatuses between
WA1 and WA7 are valid
Status of the bus coupler apparatuses between
WA2 and WA7 are valid
IEC 61850 IEC 60617
identification identification
BH_CONN -
BH_LINE_A -
BH_LINE_B -
Section 12
Control
ANSI/IEEE C37.2
device number
3
3
3
289
