Section 16
Station communication
16.5.3
Table 451: GOOSEVCTRCONF Non group settings (basic)
Name
SendOperation
SendInterval
ReceiveOperation
ReceiveInterval
16.6
16.6.1
16.6.2
16.6.3
542

Settings

Values (Range) Unit
Off -
On
0.1 - 5.0 s
Off -
On
0.1 - 10.0 s
GOOSE voltage control receiving block
GOOSEVCTRRCV

Identification

Function description
GOOSE voltage control receiving block

Functionality

GOOSEVCTRRCV component receives the voltage control data from GOOSE
network at the user defined rate.
This component also checks the received data validity, communication validity and
test mode. Communication validity will be checked upon the rate of data reception.
Data validity also depends upon the communication. If communication is invalid then
data validity will also be invalid. IEC 61850 also checks for data validity using
internal parameters which will also be passed to the DATAVALID output.

Function block

GOOSEVCTRRCV
BLOCK VCTR_RCV
DATAVALID
COMMVALID
IEC10000252-1-en.vsd
IEC10000252 V1 EN
Figure 241: GOOSEVCTRRCV function block
Step Default
- On
0.1 0.3
- On
0.1 0.8
IEC 61850
identification
GOOSEVCTRR
CV
TEST
1MRK 504 135-UEN A
Description
Send operation
Send interval
Receive operation
Receive interval
IEC 60617 ANSI/IEEE C37.2
identification device number
- -
Technical manual
