Settings - ABB RET650 Technical Manual

1MRK 504 135-UEN A
13.2.5
Table 281: TMAGGIO Group settings (basic)
Name Values (Range)
Operation
PulseTime
OnDelay
OffDelay
Table continues on next page
Technical manual
Name
INPUT10
INPUT11
INPUT12
INPUT13
INPUT14
INPUT15
INPUT16
INPUT17
INPUT18
INPUT19
INPUT20
INPUT21
INPUT22
INPUT23
INPUT24
INPUT25
INPUT26
INPUT27
INPUT28
INPUT29
INPUT30
INPUT31
INPUT32
Table 280: TMAGGIO Output signals
Name
OUTPUT1
OUTPUT2
OUTPUT3

Settings

Unit
Off -
On
0.050 - 60.000 s
0.000 - 60.000 s
0.000 - 60.000 s
Type Default Description
BOOLEAN 0 Binary input 10
BOOLEAN 0 Binary input 11
BOOLEAN 0 Binary input 12
BOOLEAN 0 Binary input 13
BOOLEAN 0 Binary input 14
BOOLEAN 0 Binary input 15
BOOLEAN 0 Binary input 16
BOOLEAN 0 Binary input 17
BOOLEAN 0 Binary input 18
BOOLEAN 0 Binary input 19
BOOLEAN 0 Binary input 20
BOOLEAN 0 Binary input 21
BOOLEAN 0 Binary input 22
BOOLEAN 0 Binary input 23
BOOLEAN 0 Binary input 24
BOOLEAN 0 Binary input 25
BOOLEAN 0 Binary input 26
BOOLEAN 0 Binary input 27
BOOLEAN 0 Binary input 28
BOOLEAN 0 Binary input 29
BOOLEAN 0 Binary input 30
BOOLEAN 0 Binary input 31
BOOLEAN 0 Binary input 32
Type Description
BOOLEAN OR function betweeen inputs 1 to 16
BOOLEAN OR function between inputs 17 to 32
BOOLEAN OR function between inputs 1 to 32
Step Default
- On
0.001 0.150
0.001 0.000
0.001 0.000
Section 13
Description
Operation Off / On
Output pulse time
Output on delay time
Output off delay time
Logic
375
