Functionality

GOOSEMVRCV is used to receive measured value using IEC61850 protocol via
GOOSE.

Function block

GOOSEMVRCV
BLOCK
DATAVALID
COMMVALID
IEC10000251-1-en.vsd
IEC10000251 V1 EN
Figure 244: GOOSEMVRCV function block

Signals

Table 460: GOOSEMVRCV Input signals
Name
BLOCK
Table 461: GOOSEMVRCV Output signals
Name
MVOUT
DATAVALID
COMMVALID
TEST

Settings

Unit
Off -
On

Operation principle

The DATAVALID output will be HIGH if the incoming message is with valid data.
The COMMVALID output will become LOW when the sending IED is under total
failure condition and the GOOSE transmission from the sending IED does not happen.
The TEST output will go HIGH if the sending IED is in test mode.
^MVOUT
TEST
Type Default Description
BOOLEAN 0
Type Description
REAL
BOOLEAN
BOOLEAN
BOOLEAN
Step Default
- Off
Station communication
Block of function
Measurand value output
Data valid for measurand value output
Communication valid for measurand value output
Test output
Description
Operation Off/On
