Table 293: XOR Output signals
Name Type
OUT BOOLEAN
NOUT BOOLEAN
Settings
The function does not have any parameters available in Local HMI or Protection and
Control IED Manager (PCM600).

Loop delay function block LOOPDELAY

Function description
Logic loop delay function block
The Logic loop delay function block (LOOPDELAY) function is used to delay the
output signal one execution cycle.
Function block
LOOPDELAY
INPUT
IEC09000296-1-en.vsd
IEC09000296 V1 EN
Figure 172: LOOPDELAY function block
Signals
Table 294: LOOPDELAY Input signals
Name Type
INPUT BOOLEAN
Table 295: LOOPDELAY Output signals
Name Type
OUT BOOLEAN
Settings
The function does not have any parameters available in Local HMI or Protection and
Control IED Manager (PCM600).
Description
Output signal
Inverted output signal
IEC 61850
identification
LOOPDELAY
OUT
Default Description
0 Input signal
Description
Output signal, signal is delayed one execution
cycle
