Table 170: SDDRFUF Group settings (basic)
Name Values (Range)
Operation
OpMode
3U0>
3I0<
3U2>
3I2<
OpDUDI
DU>
DI<
UPh>
IPh>
SealIn
USealln<
IDLD<
UDLD<
Table 171: SDDRFUF Non group settings (basic)
Name Values (Range)
GlobalBaseSel
Technical manual

Settings

Unit
Off -
On
Off -
UNsINs
UZsIZs
UZsIZs OR UNsINs
UZsIZs AND
UNsINs
OptimZsNs
1 - 100 %UB
1 - 100 %IB
1 - 100 %UB
1 - 100 %IB
Off -
On
1 - 100 %UB
1 - 100 %IB
1 - 100 %UB
1 - 100 %IB
Off -
On
1 - 100 %UB
1 - 100 %IB
1 - 100 %UB
Unit
1 - 6 -
Secondary system supervision
Step Default
- On
- UZsIZs
1 30
1 10
1 30
1 10
- Off
1 60
1 15
1 70
1 10
- On
1 70
1 5
1 60
Step Default
1 1
Section 11
Description
Operation Off / On
Operating mode selection
Operate level of residual overvoltage
element in % of UBase
Operate level of residual undercurrent
element in % of IBase
Operate level of neg seq overvoltage
element in % of UBase
Operate level of neg seq undercurrent
element in % of IBase
Operation of change based function
Off/On
Operate level of change in phase voltage
in % of UBase
Operate level of change in phase current
in % of IBase
Operate level of phase voltage in % of
UBase
Operate level of phase current in % of
IBase
Seal in functionality Off/On
Operate level of seal-in phase voltage in
% of UBase
Operate level for open phase current
detection in % of IBase
Operate level for open phase voltage
detection in % of UBase
Description
Selection of one of the Global Base Value
groups
