I103SUPERV Non group settings (basic)

Values (Range)

FunctionType

Technical manual

Function block

IEC10000293-1-en.vsd

IEC10000293 V1 EN

I103SUPERV function block

I103SUPERV Input signals

Status for user defined signals for IEC 60870-5-103

I103USRDEF is a function blocks with user defined input signals in monitor

direction. These function blocks include the FunctionType parameter for each block

in the private range, and the information number parameter for each input signal.

Block of status reporting

Information number 32, measurand supervision of I

Information number 33, measurand supervision of

Information number 37, I high-high back-up

Information number 38, fuse failure VT

Information number 46, group warning

Information number 47, group alarm

Function type (1-255)
