Section 12
Control
12.7.4
12.7.5
Table 256: SPC8GGIO Non group settings (basic)
Name
Operation
Latched1
tPulse1
Latched2
tPulse2
Latched3
tPulse3
Latched4
tPulse4
Latched5
tPulse5
Latched6
tPulse6
Table continues on next page
360

Signals

Table 254: SPC8GGIO Input signals
Name
BLOCK
PSTO
Table 255: SPC8GGIO Output signals
Name
OUT1
OUT2
OUT3
OUT4
OUT5
OUT6
OUT7
OUT8

Settings

Values (Range) Unit
Off -
On
Pulsed -
Latched
0.01 - 6000.00 s
Pulsed -
Latched
0.01 - 6000.00 s
Pulsed -
Latched
0.01 - 6000.00 s
Pulsed -
Latched
0.01 - 6000.00 s
Pulsed -
Latched
0.01 - 6000.00 s
Pulsed -
Latched
0.01 - 6000.00 s
Type Default Description
BOOLEAN 0 Block of function
INTEGER 2 Operator place selection
Type Description
BOOLEAN Output 1
BOOLEAN Output 2
BOOLEAN Output 3
BOOLEAN Output 4
BOOLEAN Output 5
BOOLEAN Output 6
BOOLEAN Output 7
BOOLEAN Output 8
Step Default
- Off
- Pulsed
0.01 0.10
- Pulsed
0.01 0.10
- Pulsed
0.01 0.10
- Pulsed
0.01 0.10
- Pulsed
0.01 0.10
- Pulsed
0.01 0.10
1MRK 504 135-UEN A
Description
Operation Off/On
Setting for pulsed/latched mode for output
1
Output 1 Pulse Time
Setting for pulsed/latched mode for output
2
Output 2 Pulse Time
Setting for pulsed/latched mode for output
3
Output 3 Pulse Time
Setting for pulsed/latched mode for output
4
Output 4 Pulse Time
Setting for pulsed/latched mode for output
5
Output 5 Pulse Time
Setting for pulsed/latched mode for output
6
Output 6 Pulse Time
Technical manual
