Table 189: QCBAY Non group settings (basic)
Name Values (Range)
AllPSTOValid
12.1.6
12.1.6.1
12.1.6.2
12.1.6.3
12.1.6.4
Technical manual

Settings

Unit
Priority -
No priority

Local remote LOCREM

Identification

Function description
Local remote

Functionality

The signals from the local HMI or from an external local/remote switch are applied via
the function blocks LOCREM and LOCREMCTRL to the Bay control QCBAY
function block. A parameter in function block LOCREM is set to choose if the switch
signals are coming from the local HMI or from an external hardware switch connected
via binary inputs.

Function block

LOCREM
CTRLOFF OFF
LOCCTRL LOCAL
REMCTRL REMOTE
LHMICTRL VALID
IEC09000076_1_en.vsd
IEC09000076 V1 EN
Figure 119: LOCREM function block

Signals

Table 190: LOCREM Input signals
Name
CTRLOFF
LOCCTRL
REMCTRL
LHMICTRL
Step Default
- Priority
IEC 61850
identification
LOCREM
Type Default Description
BOOLEAN 0 Disable control
BOOLEAN 0 Local in control
BOOLEAN 0 Remote in control
INTEGER 0 LHMI control
Section 12
Description
Priority of originators
IEC 60617 ANSI/IEEE C37.2
identification device number
- -
Control
263
