Shift - Ag Leader Integra Display Operator's Manual

Straight
Reset
Nudge: 30.0 in
Total: 0.0 in
the Mapping Toolbox, if Tramlines are enabled.
Press: Map button > Guidance tab (in Mapping Toolbox) > Setup (wrench) button > Nudge tab
Guidance Options
Nudge

Shift

Lightbar
Save
Save
Group
Small Increment:
Pause
Large Increment:
Remark A
Total Nudge:
S
HIFT
Press: Map button > Guidance tab (in Mapping Toolbox) > Setup (wrench) button > Shift tab
138
Nudge allows you to adjust the
swaths by a specified distance.
Small Nudge (single arrow) shown on left.
Large Nudge setting (double arrow) shown on
right (Straight Patterns Only).
Use Nudge toggle button
switch between Small and Large Nudge setting.
Use Mapping Toolbox toggle button
switch the menu between Tramline and Nudge on
Nudge
Tramlines
30.0 in
90.0 in
Clear Nudge
0 in
Shift
Nudge: 30.0 in
to
Total: 0.0 in
Press the Setup (wrench) button then the
Nudge tab to make adjustments to Nudge settings.
• Press to enter a distance for increment that
the swaths will move with each successive press of the
left or right arrows buttons on the Guidance Tab.
• To clear out the adjustment and go to the original
position, press Clear Nudge.
Screen shows Small and Large increment settings
for Straight path. Other Patterns will only show the
small increment setting.
Straight
Reset
Nudge: 90.0 in
Total: 0.0 in
to
Firmware Version 6.0
