• (F) Singulation
Displays the average Singulation for the planter, or selected sections of the planter, along with the highest
and lowest rows.
- singulation is a measure of the percent of seeds being properly metered so that one and only one seed
drops from each seed cell of the seed meter.
• (G) Skips/Doubles
Displays the average skips and doubles for the planter
- skips are a measure of the percentage of seed expected to be planted that do not due to a seed not
being dropped by the seed meter.
- doubles are a measure of the percentage of seed expected to be planted individually but instead two or
more are dropped by the seed meter.
• (H) Seed Monitor Setup
Pressing this button brings up Seed Monitor Options screen.

Row Performance screen

The Row Performance screen displays information on specific rows.
Press: Bar Graph button. The Bar Graph button toggles between the Planter Performance
screen and the Row Performance screen.
38.4
ac
Row 1 Performance
Population Singulation
Spacing Quality
Skips
Doubles
Seed Spacing
Singulation History
• (M) Zoom In
• (N) Zoom Out
Toggle through the rows using the arrow buttons or press on a specific row in the bar graph.
Previous Row button
The Singulation History/Spacing Quality History bar graph gives a 10 second for each row.
206
5.0
mph
Errors: 0%
Next Row button
• (A) Row Indicator
• (B) Population
• (C) Spacing Quality
• (D) Seed Spacing
• (E) Singulation
• (F) Skips
• (G) Doubles
• (H) Singulation History/Spacing
Quality History toggle
• (I) Errors
• (J) Bar Graph
• (K) Virtual Seed Trench
• (L) Play/Pause button
Firmware Version 6.0
