• Clear Bounds button
Press to center the map on the current GPS position.
Note: The Clear Bounds feature is particularly useful if you have flyer points or have logged a point outside
the mappable range of your current location.

Importing and Exporting Field Boundaries

Boundaries can be created with the display or imported from desktop GIS software. Any boundary files
present in the display can also be exported for use in desktop mapping software.
Note: For more information on creating boundaries, see
Grower/Farm/Field
Season
Grower: Gene Eilers
Farm: Sheldon
Field: Low 80
Grower: Seth
File Selection
Name
Boundaries
New Folder 1
Field_1.iby
Field_2.iby
Field_3.iby
Field_4.iby
irx_multi_product
irx_single_product
• USB Export button
To export a boundary to the USB drive, highlight the correct field in the Farm/Field list and
press the USB Export button. At the File Selection screen, highlight the desired field to export.
A screen will appear telling you that the boundary was exported successfully. Press
field setup screen.
32
Management Setup
Businesses
Users
True Area:
40 ac
Boundary
39.92 ac
Demo
Field:
Farm:
Allegon County
Grower:
Michigan Test Fields
91.51 ac
"Create Boundary" on page
Contacts
USB Import button
To import a boundary from the USB drive, first go
to the Setup Field tab, highlight the correct field in
the Farm/Field list and press the USB Import
button.
Clear
The File Selection screen appears. Highlight the
desired file to import.
Operator can import/export all fields and boundaries
at once with an .AGSETUP file. For more
information on .AGSETUP files see
on page 353.
Press
to complete the import process.
55.
See ".AGSETUP"
return to the
Firmware Version 6.0
