Legend Settings
On the Legend Select screen, press legend, and the Legend Settings screen appears. The
Legend Settings screen allows you to change the default legend.
Legend Settings
Attribute: Rate
Average
16.0 - (20.0)
12.0 - 16.0
175
8.0 - 12.0
4.0 - 8.0
(0.0) - 4.0
Range Spacing
10
Automatic
Legend
The Legend Settings screen includes the following items:
52
Color Scheme
Reset to Default
Green-Yellow-Red
Legend
Ranges
Save as Product
Legend
5
Load
Press
. Select the reference map you want to
Reference
use.
Reference Map Wizard displays each operation
performed in field, filtered by season. The map can be
displayed as an As-Applied or Coverage.
Press
to continue.
Select the Autoswath channel to apply the reference
map to
Not selecting a channel will load the reference map as
a visual only
Press
to complete Reference Map Wizard.
Note: Using Reference maps for AutoSwath functionality is
applicable to planting and application configurations only.
Notes:
• The Legend Settings screen can also be accessed by
pressing the Edit Legend button on the Setup screen's
Product Tab.
• Legend settings changes that are made at the Legend
Settings screen will affect all regions.
Firmware Version 6.0
