Seed Monitor
Press: Home button > Setup (wrench) button > Configuration (tractor) button > Configuration tab > your
specific configuration > Setup (wrench) button > Seed Monitor button
Seed Monitor
Split Rows
Standard Rows
0
16
Note: Press the Sensor to perform the AutoConfig procedure, which is necessary for a Seed Tube Monitor
Module configuration to become active. Fore more information, see
• Press the Alarms button to summon the Seed Monitor Alarms screen, which shows each row and the
alarm threshold for that row. For more information, see
AutoConfig Procedure
The AutoConfig procedure assigns individual rows to the appropriate pins on the Seed Tube Monitor
Module.
Seed Monitor
Press: Home button > Setup (wrench) button > Configuration (tractor) button > Configuration tab > your
specific configuration > Setup (wrench) button > Seed Monitor button > Sensor Configuration button >
AutoConfig button
196
S
ETUP
Configuration
Speed Source
Sensor
Configuration
GPS
Thresholds
Alarms
Configuration
Sensor Configuration
Select Your Specific
Configuration
• The Split Rows and Standard Rows settings show
the number of rows found on the planter that the Seed
Tube Monitor Module supports. Use
to enter the total number of rows found on the planter.
• The Speed Source shows the selected Ground Speed
Source input for the Seed Tube Monitor Module. Press
the Sensor to summon the Sensor Configuration
window, which shows which rows are assigned to the
individual pins on the Seed Tube Monitor Module.
"AutoConfig Procedure" on page
"Seed Monitor Alarms" on page 199
Select Your Specific
Configuration
AutoConfig
/
196.
.
Firmware Version 6.0
