Strip Till Control
Channel 1
Channel 2
Channel 3
MAP
Product
Density
Conveyor 1
Rate
In-Field
Static
Prime
Calibration
Calibration
Air Cart Prime
Channel 1
Revolutions
0.25
Channel 2
Revolutions
0.25
Channel 3
Revolutions
0.25
Note: Meter Prime routine is not available and remains hidden for ground driven metering configurations.
Strip Till Control
Channel 1
Channel 2
Channel 3
Control Valve Configuration
Single Bin Actuator
Actuator
Actuator
Response
Response 1
Response 2
Threshold
18 %
90 %
Ag Leader PN 4002083 Rev. N
62 lb/ft3
0 ft3/rev
1 2 3
Start
Prime
Auxiliary
Allowable
Shaft Speed
Error
Calibration
4
180 pls/rev
2 %
Max Metering
Speed
100 rpm
The Strip Till Control screen appears.
Press the Prime button to access the Air Cart Prime
screen.
The Air Cart Prime screen appears with input
buttons for each channel used. The setting
determines the revolutions necessary to prime the
meter shaft. Settings are independent by channel,
and can be entered using
(A) Start Prime
(B) Channel 1 Revolutions
(C) Channel 2 Revolutions
(D) Channel 3 Revolutions
A
PPLICATION
.
325
