Possible Cause: The reference file selected exceeded the allowable memory limit used to load
reference maps.
Solution: Continue harvest operations. All variety tracking and region information will be
logged. However you will not be able to see the entire reference map on the display's
map screen.
G H
RAIN ARVEST
When performing a Harvest operation, you can also access the Harvest Diagnostic screen
by pressing the Display Information button. Technical support may request that you look at
this screen for help in diagnosing a problem. When the Devices screen opens, press and
highlight the Moisture Module listing in the CAN Device list, then press the Diagnostics button. The Grain
Harvest Diagnostics screen appears.

Grain Harvest Diagnostics

Region Distance
Flow Rate 5.12
Flow Max 216
172
Flow Mn
Flow Offset 350
Sensor Force 9.95
Header Raw
296
Speed Pulse 103
• Speed Pulses
Shows the number of ground speed pulses from the combine.
• Moisture Raw
Raw value of moisture sensor.
• Temperature
Air temperature, shown in Celsius.
• Temperature Raw
Raw value of temperature sensor.
• Proximity Sensor
Shows if Elevator Mount Unit sensor is covered with grain.
• Relay Status
Shows on or off.
• Motor Current
Measure of Elevator Mount Unit (EMU) current, shown in amps.
Ag Leader PN 4002083 Rev. N
D
IAGNOSTICS
18257 ft
Moisture Raw
3.21
Temperature -3.8
Temperature Raw
2.69
Proximity Status ON
Relay Status ON
Motor Current
0.9
The Grain Harvest Diagnostics screen includes the
following information:
• Flow Rate
Grain flow rate, shown in kilograms per second.
• Flow Max, Flow Min and Flow Offset
Raw flow values used for diagnostic purposes.
• Sensor Force
Force of grain flow, shown in Newtons.
• Header Raw
Raw value of header sensor.
H
ARVEST
