Ag Leader Integra Display Operator's Manual page 240

9. Assign Container Capacity
Press to enter the container capacity. Press
10. Enter Container Units
Use the drop-down menu to select the container units.
Once container has been configured press
11. Enter Swath Width
Press to enter swath width.
12. Enter Number of Boom Sections
Press /
13. Enter Boom Section Widths
Highlight specific boom section and press
sections must equal swath width.
14. Enter Application Point Offset
Press to enter distance from hitch to application point (front to back). Press
value on offset screen. Press
If setting up a Self-Propelled Applicator, enter the distance from rear axle to application point.
Note:
Use drop-down menu to select distance Behind or In Front.
At this point additional functionality can be added to the implement, such as direct injection.
Note:
If no additional functionality is being added, press
15. Add Additional Devices (optional)
Press
Norac UC5
Press
OptRx Crop Sensor
• Press to enter sensing width (defaults to implement width, change only if necessary).
• Use /
• Press Swath Offsets button to enter offsets. System can not be configured with sensors and application
point on opposite sides of the hitch.
Press to continue.
224
to enter number of boom sections.
to accept value for the application point.
to add boom control functionality.
to add boom sensor functionality.
to enter number of sensors.
to accept.
to continue.
to enter boom width. The total width of all boom
to continue.
to accept
Firmware Version 6.0
