C L
ONTAINER EVEL
Rate Control Settings
Rate Control Containers
Tank 1 - Product 1
Full: 800
Current: 700
Tank 2 - Product 2
Full: 400
400
Current:
Tank 3 - Product 3
Full: 200
Current: 200

Tank Fill

The Tank Fill button increases the container level logged in the display to the user-defined
maximum volume (specified in the Container Setup Wizard).

Tank Empty

The Tank Empty button decreases the container level logged in the display to zero.

Tank Partial Fill

The Tank Partial Fill button increases the container level logged in the display to specific
amount that you specify by pressing
Adjust Container Amount screen.

Adjust Container Amount

Adjust Container Amount
Add Add product to the container
Remove Remove product from the container
Set Set the product level in the container
242
S
ETTINGS
80
10 %
40
10 %
20
10 %
When filling or emptying container, use the
Container Level portion of the Rate Control Settings
screen to update the amount of product in the
containers.
Container Level screen - (Partially Full)
. Pressing the Partial Fill button summons the
• Add
Adds product to the container. Press
the amount.
• Remove
Removes product from the container. Press
enter the amount.
• Set
Sets the product level in the container. This button
summons the , where you can set a certain
amount. Choose an amount that is below your maximum
container level.
to enter
to
