Markers Tab - Ag Leader Integra Display Operator's Manual

• Attribute
Attribute: Yield
Appears at the top left of the Legend Settings screen. Attributes shown for Harvest
205 - (225)
185 - 205 include Yield and Moisture. The Rate attribute is shown for Planting and Application
165 - 185
operations. You can adjust the color scheme, spacing and ranges as they appear on the
145 - 165
(125) - 145
map screen, by using the buttons described below.
• Average
The Average button changes the average rate for the legend. Press
ranges shown on the map legend.
• Range Spacing
The Range Spacing button changes the difference between the rates in one color range. Press
edit the legend range spacing value, which is the total number of units represented by a particular color.
• Ranges
The Ranges
• Color Scheme
The Color Scheme can be modified by using the drop-down list. Choices include the following:
- Green-Yellow-Red
- Single Hue (blues or greens)
- Rainbow
• Reset to Default Legend
Resets the legend to the default settings.
• Automatic Legend
If the Automatic Legend checkbox is selected, the average automatically sets itself to the field average and
updates as the field average changes
• Reset to Default Legend
Press the reset legend to the system default.
• Save as Product Legend
Select the Save as Product Legend checkbox if you wish to set the current legend as the default legend for
all regions of the same product.

Markers tab

Markers
Rock
Weeds
Washout
Hole
Ag Leader PN 4002083 Rev. N
/ change the number of range increments displayed in the legend.
Markers are a collection of point objects that are available on the Map Markers
tab of the Mapping Toolbox. Map markers allow you to map points on the go in
order to identify specific features within a field. Press an individual marker to
indicate a Map Marker on the Map screen.
If all of the Markers that you created are not immediately visible in this screen,
use the Cycle Markers button to view more that you created.
Cycle Markers
S
ETUP
