• Split Rows Enabled
Check this box to enable the display to log data from the planter's Split Row units. (For split row-enabled
planters, you will need to create separate implement configurations for Split Row and non-Split Row
operations).
• Planter Section Clutch Control
Check the Planter Section Clutch Control check box if you are using Row Shutoff module.
• Down Force
Check the Down Force check box if you are using Down Force module.
8. Rate Controller
Select an existing rate controller from the drop-down menu, or press
with the Controller Setup Wizard. Press
Controller Wizard:
Select Device: Seed Command
Select Device Type:
- Hydraulic Controller
- Stepper Controller
- Granular Strip Till Controller
Enter Number of drives
Enter Controller Name
9. Enter Number of Rows and Spacing.
Use
/
continue.
10. (AutoSwath Only) Number of Implement Sections
Enter the number of swath sections that can be independently turned on and off.
Note: The Clutch Module Configuration must match the actual number of row sections on the planter.
Otherwise, if you try to load a Field Operation at the Field Operation Wizard, you will see a message stating
that "The number of detected module outputs does not equal the number of planter sections."
11. (AutoSwath Only) Enter Section Widths from Left to Right
Enter how many rows are in each swath section from left to right screen appears. This screen shows the
number of sections and number of rows in your configuration. From here you can:
Press
-
- Highlight the section number, and use
to continue.
Note: The implement is divided up into equal section sizes by default. To modify the sections, press the
keypad button for each section that needs to be changed.
12. Add Liquid or Granular Application
13. Enter Implement Name
Press
to enter an Implement Name, Press
162
to enter the number of rows. Press
to continue.
, or
to continue.
and enter spacing. Press
to change the section row numbers; then press
to complete Implement Wizard.
and create a new controller
Firmware Version 6.0
