Planter Options - Ag Leader Integra Display Operator's Manual

P O
LANTER PTIONS
Settings
Press: Map button > Settings button > Seed Monitor tab
or
Press: Advanced Seed Monitoring button > Setup (wrench) button > Seed Monitor tab

Planter Options

Planter Drives
Seed Monitor Down Force
Ignore population alarms
Population
Alarms when row clutches turn off
• Singulation Alarm
• Spacing Alarm
• Alarms button
Press to access the Seed Monitor Alarms screen, explained below.
• Ignore seed alarms when row clutches turned off check box
Note: For corn, do not change the Default Gain setting of 1.
198
Seed Monitor
Seed Monitor
Gain
1
Advanced Seed Monitoring
Thresholds
Singulation Alarm
98 %
Spacing Alarm
98 %
Diagnostics
The Planter Options screen adjust Seed Tube
Monitor Module alarm thresholds.
• Gain shows the population adjust value used to adjust
the population if the seed tube is not sensing the actual
seed population.
- For the correct Gain setting, please refer to planter's
operator manual.
- Gain Setting is saved by crop type when using firmware
version 3.0 and higher.
- For Corn Gain values should be set to 1.
Advanced Thresholds
- Double Seed threshold
- Poor Spacing threshold
Firmware Version 6.0
