GPS Port Setup - PORT A
Output Type TSIP
Output Baud Rate 4800
Output Parity
None
1
GPS Pos. Rate (Hz)
Output Rate (Hz) ASAP
GPS I
NFORMATION
To access diagnostic information about the GPS signal, press the GPS (satellite) button
that appears in the in the upper left-hand side of the Status Bar. GPS Information then
appears on General, Receiver, and OmniSTAR tabs. Information on these GPS Information
screens is described on the following pages.
GPS button with bars - bars indicate cellular signal strength
112
NMEA Messages
GGA (Position) GSA
VTG (Speed) ZDA
GLL RMC
MSS
GSV
The appearance of the Port B tab is
similar to Ports A.
GGA(Legacy) - shortens the decimal
precision of the GGA message for
connection to legacy equipment.
The appearance of this TSIP receiver GPS Port Setup
screen is the same for both Ports A and B.
Firmware Version 6.0
