Guidance Options - Ag Leader Integra Display Operator's Manual

P
AUSE
Press: Map button > Guidance tab (in Mapping Toolbox) > Setup (wrench) button > Pause button
The Pause button allows your display to stop logging points along an AB Line. Once this button is
pressed, a Resume button will take its place until you press this button and Pause reappears.
Note: If you are using the display to follow a set AB Line and wish to temporarily deviate from this line, you
can use the Pause button to pause the display's guidance logging activity. This feature could be used, for
example, by a vehicle operator who must refill a sprayer. When paused, the display will continue to give the
distance back to the original pause point position.
• Press Pause button.
Press the Pause button on the Guidance screen. When you do so, the place where you
Pause
paused appears on the Map screen as a yellow ball.
Note: You can pause a pattern even if you have not set the "B" point yet. If you do so, the message in the
lightbar will read "Need B." If you pause the pattern after you have set your AB Line, then the lightbar will
indicate the distance your vehicle must travel to return to the pause point.
• Press Resume button.
To resume your pattern, press the Resume button to resume logging on your AB Line.
Resume
Note: If you press the Resume button before you have returned to the original AB Line, your display will select
the closest AB Line to your vehicle.
R A
EMARK
Press: Map button > Guidance tab (in Mapping Toolbox) > Setup (wrench) button > Remark A button
If you chose Straight patten, the Remark A button appears on the Guidance Options screen. The
Remark A button "re-marks" the A point by moving it to the current position while maintaining the same
heading. A brief message appears in the on-screen lightbar, stating "Point A Remarked."
N
UDGE
Note: Only Straight patterns offer two Nudge settings. All other patterns have a single nudge setting.
Ag Leader PN 4002083 Rev. N
Pause
Remark A
137
