Auxiliary Mappings
Function
Note: Implement functions can not be mapped to
VT A
LARMS AND
Virtual Terminal Alarm
Low fan speed detected
Disable Main
Drive Shutoff
CAN A CAN B
130 ISO NODE
92
Input
T
ROUBLE
Devices
CAN Name: 76 10 2B DB 00 B0 0C A0
Self Configurable: Yes
Agriculture and Forestry
Industry Group:
Device Class: Sprayers
Device Class Instance: 0
Function: 128
0
Function Instance:
ECU Instance
0
Identity Number: 725110
Manufacturer Code: 89
Kverneland Group, Electronics Division
Assign implement functions to ISO compatible
inputs.
The number of functions and inputs shown on the
Auxiliary Mappings screens will vary depending on
the implement and input devices connected to the
display.
Ag Leader
switches.
C
ODES
If the display receives an active trouble code, the
Virtual Terminal Alarm (A) will appear in the
Status bar at the top of the screen.
When an alarm is activated on the VT, the display
will indicate the alarm by flashing "Virtual Terminal
Alarm" in the status bar.
Alarms are acknowledged and cleared by pressing
.
This button is only present when a virtual terminal
alarm has been activated.
The Devices screen displays the following
information:
• (A) Caution icon indicates module has active
trouble codes (DTCs)
• (B) Equipment Type
• (C) ECU Serial Number
• (D) VT Manufacturer, name and code
Firmware Version 6.0
