Ag Leader Integra Display Operator's Manual page 334

2. Select Implement
Select an implement from the drop-down list menu, or press
to continue.
3. Select Planter/Seeder Type
Use drop-down menu and select Air Seeder from the list. Press
4. Enter Implement Information
Press and enter implement Make and Model. Press
5. Select Implement Attachment Type
Use the drop-down list to select an implement attachment method. Press
6. Enter Distance Application Point Offset
Use to enter distance from hitch to application point (Front to Back). Press
7. Select Controller
Use the drop-down menu to select controller or press
continue.
8. Select Controller Device and Device Type
Select DirectCommand from the Device drop-down menu. Select Granular Strip-Till Control from the
Device Type drop-down menu. Press
9. Enter Controller Name
Controller name defaults to Direct Strip Till. Press
name if desired. Press
10. Enter Full Swath Width
Full Swath width defaults to a value of 30 ft. Use
Press to continue.
11. Select Application Type from the Implement Wizard:Application Channels screen.
Press the Granular Application button.
12. Select Controller
Use the drop-down menu to select same controller as above. Press
13. Container Setup (Equipment Setup Wizard: Container screen)
Press the desired channel button in order to enable or disable the controller channel. A check mark will
appear in the box when the container is ready to be configured.
Channel 1 is automatically assigned as a seeding channel and is intentionally unavailable for
Note:
user to edit. Proceed with configuration of containers for channels 2 and 3.
318
to continue.
to continue.
to create a new implement. Press
to continue.
to continue.
to add a controller. Press
to accept, or press
to enter the full swath width of the implement.
to continue.
to continue.
to continue.
to
to enter a new
Firmware Version 6.0
