Smart
Reset
Nudge: 30 in
Total: 0 in
The system guidance created this path when you created the Base Path. This is the path that your vehicle
would have taken if you had turned it in the opposite direction.
• SmartPath Notes:
- The Projected Path and Base Path both remain in display memory, unless you press the Reset button
without saving the SmartPath pattern.
- Pressing the Save button saves all the SmartPath passes within the display's memory for future use.

Select a Previous SmartPath Pass

If you have specified SmartPath as your desired pattern, but you are not following an active guidance
pattern, the Guidance System automatically begins searching for SmartPath patterns for your use.
If you wish to use a previously-created SmartPath pattern, you can do so by pressing on
the Active Line Cycle button. This button allows you to cycle between available SmartPath
patterns.
• Notes:
- When the guidance system looks for other available SmartPath patterns, it first displays the nearest-
available pass.
- You can adjust the available area in which the Guidance System searches for previously-created
SmartPath passes. To do this, adjust the Heading Threshold settings on the Smart Tab of the
Guidance Option screen.
SmartPath Guidance Options
SmartPath only creates a SmartPath pass when you are logging data in the field. However,
you have the option of using it to create SmartPath passes continually during all field
operations.
132
As you continue using the SmartPath,
the map screen will display three lines:
• (A) The Base Path
Appears as a black line, is the initial
SmartPath that you created on the first
pass.
• (B) The Followed Path
Appears as a maroon-colored line, is the
path that your vehicle is currently using.
• (C) The Projected Path
Appears as a blue-colored line on the
opposite side of the Base Path, is an
alternate path parallel to the Base Path.
Firmware Version 6.0
