The Accessories menu is used to activate or deactivate optional sensors. Currently only the remote
engaged switch is available. These options are always displayed when available. Once activated, the
system is aware that the sensor is installed and functional. When options are functional diagnostic
information is gathered and any malfunction of the sensor is reported through the diagnostic manager. If
the sensor is removed warnings and errors are reported until the sensor is deactivated in the system.
The Remote Engage Switch is an optional device that allows AutoSteer to be engaged from
Note:
a device such as a foot switch or push button instead of pushing the Engage button on the display.
A Remote Engage Switch must be activated in the Accessories menu.
Remote Engage Switch
Press the Enable button to activate the Remote Engage Switch. The Remote Engage Switch enabled
screen appears. To disable the Remote Engage Switch at a later time, return to the screen and press the
Disable button.
T
ECHNICIAN
System
Press: System button > Technician button
The Technician screen is password protected for use by qualified service technicians only.
S U
OFTWARE PGRADE
System
Press: System button > Software Upgrade button
The Software Upgrade screen enables you to upgrade your system with the latest application software:
1. Insert a USB drive (containing software upgrade) into Display.
2. Press Software Upgrade button.
3. Press Choose File button.
4. Select the desired software from list and press checkmark.
The upgrade process goes through a series of steps and reboots the AutoSteer system after a successful
upgrade.
5. Press checkmark button after the upgrade is complete.
The AutoSteer system is now ready for normal operation.
GPS D
IAGNOSTICS
GPS
Press: GPS button > GPS Diagnostics button
The GPS Diagnostics screen displays the following operational parameters:
154

Technician

Software
Upgrade
GPS
Diagnostics
Firmware Version 6.0
