Section Offsets
Offsets
Planting with SeedCommand 2
Enter Forward or Backward Distance from Hitch Point
Enter Left or Right Distance from Centerline
Note: Accuracy when measuring and entering implement offsets is required to ensure proper machine
performance.
swath section offset measurements.
Ag Leader PN 4002083 Rev. N
5 ft
0 ft
Left
Advanced
• Press the first
swath section is located from the hitch point.
• Press the second
the mid-point of the swath section to the machine's
centerline. Select to the left/to the right to indicate the
direction the swath section is located from the vehicle
centerline.
• Press
when finished.
S
ETUP
to enter the distance that the
to enter the distance from
87
