7. Select Controller Device
Select DirectCommand from the Device drop-down menu. Select Granular Strip-Till Control from the
Device Type drop-down menu. Press
8. Enter Controller Name
Controller name defaults to DirectStrip Till. Press
name if desired. Press
9. Container Setup (Equipment Setup Wizard: Container screen)
Press the desired channel button to enable or disable controller channel. A check mark will appear in the
box when the container is ready to be configured.
10. Assign Container Name
Container name defaults to "Bin 1, 2, or 3". Press
11. Assign Container Capacity
Use to enter the container capacity. Press
12. Enter Container Units
Use the drop-down menu to select the container units. Once container has been configured press
to continue.
Follow steps 9-12 for each control channel.
Note:
13. Enter Full Swath Width
Full Swath width defaults to a value of 30 ft. Use
Press to continue.
14. Enter Application Point Offset
Use to enter distance from hitch to application point (front to back). Press
At this point additional functionality can be added to the implement. If no additional
Note:
functionality is being added, press
15. Add Additional Devices (Optional)
Press OptRx Crop Sensor button to add sensor functionality. Use
/ to enter number of sensors. Press
16. Hitch Point Configuration
Press the Implement Provides a Hitch Point button to enter Hitch Point information. Use
Left or Right distance. Use drop-down menu to indicate distance to the left or right. Use
Forward or Backward distance. Press
316
to continue.
to continue. Press
to continue.
to continue.
to accept, or press
again to continue.
to enter a new name if desired.
to accept.
to enter the full swath width of the implement.
to enter sensing width. Use
to continue.
to enter a new
to accept.
to enter
to enter
