GPS
GPS B
UTTON
During your field operation, the GPS (satellite) button in the upper left-hand side of the
Status Bar should appear green, which means you are receiving a differential GPS signal. If
this icon appears yellow, you are still receiving GPS but are not receiving a differential
signal; and if it appears gray then you have lost GPS. In either case, you should check your GPS
settings.
S
ETUP
Press: Home button > Setup (wrench) button > GPS button
GPS/Guidance Setup
Steering
Manual Guidance
15 Minutes
S
GPS S
ERIAL
Press: Home button > Setup (wrench) button > GPS button > Serial (from Receiver drop-down box)
> Receiver Setup (wrench) button > General tab
Ag Leader PN 4002083 Rev. N
Receiver: 6500
Serial
Operator Presence Alarm
Lightbar
Settings
Require Differential
Correction for Guidance
0
ETTINGS
Reciever: GPS 6500
Serial
Guidance/Steering, Lightbar Settings,
and Required Differential Correction for
Guidance
For more information, see the Guidance
chapter at
"Guidance" on page 123
General
.
103
