Select Pattern

Press: Map button > Guidance tab (in Mapping Toolbox) > New Pattern button > Pivot Pattern Selection
System defaults pattern type to last used. Press the pattern icon to select a different pattern.
- Implement Width (from Implement Setup)
- Guidance Width input box
- Manual Entry checkbox and Latitude and Longitude input boxes
Press . You will automatically return to the Map screen.
Create AB line using driven path
• Position one wheel of the vehicle in a pivot wheel rut, with the rear of the vehicle to the pivot arm.
•
placed.
• Drive around the field. Keep the vehicle wheel in the rut.
•
- Pause - Press
- Resume - Press
- Cancel - Press
•
point B., the AB line appears on the map screen and point B is marked with a red ball.
Pivot Field Edge
Shift By
Distance
Inward
From here, you may choose one of three options:
Ag Leader PN 4002083 Rev. N
New
Pattern
Press to mark point A. A green ball appears on the map screen where point was
Button is greyed out until you drive a minimum of 160 feet.
to pause path during path creation
to resume path during path creation
to cancel path during path creation
When you are almost back to the pivot arm or the edge of the field, press to mark
Feet Inches
0 ft 30 in
Outward
1. Next, you must set the Field Edge. You may do this
when the Pivot Field Edge window appears on your
display.
