A
M
PPLICATION
19.2
ac
N
Coverage
Coverage
Overlap
L
S
EGEND
ELECT
Press: Home button > Legend tab (of the Mapping Toolbox) > Setup (wrench) button
During Area Logging Application operations, the Map screen displays coverage in the Legend.
Legend Select
NH3
Coverage
Load
Clear Map
Reference
• Press Load Reference to load a map from a previous operation performed in that field to view as a
background map.
Ag Leader PN 4002083 Rev. N
- Z
AP SCREEN
N
lb/ac
150
150
D
OOM TO
ETAIL
15.0
mph
• (A) GPS Status
2
• (B) Ground Covered
130
• (C) Ground Speed
• (D) Diagnostics button
• (E) Product tab
Flow:
544.8 lb/min
Container:
630 gal
• (F) Logging Status button
• (G) AutoSwath
80 ft
100%
• (H) Map View button
• (I) Home button
Pressure (PSI)
Main:
41
• (J) Display Legend
Agitation:
Auxi
Use the drop-down menu at the top to select your
product. Other items at this screen include:
• Press Coverage to show the area where you have
already applied a product.
• If using a DirectCommand or rate logging configuration,
press Rate to show the Rate Legend in the Mapping
Toolbox. The rate map displays the actual rate being
applied. This legend is editable. For more information,
see
"Legend Settings" on page 52
• Press Clear Map to permanently remove all map data
from the active field operation.
A
PPLICATION
.
239
