M S
AP CREEN FOR
1.06
ac
Soybeans
Yield
136 +
116 - 136
96 - 116
76 - 96
0 - 76
Moisture
The top of the Harvest Diagnostic button displays the following information:
• For configurations using a Platform Head or Pickup Head - Swath Width, shown both in units of
measurement and as a percentage total.
• For configurations using a Row Head - Number of active rows.
The Harvest Diagnostic button also displays this information for all CLAAS configurations:
• Grain Flow
• Header Height - shown as a percentage
• Engine Speed - shown in revolutions per minute
• Fuel - fuel consumption of the combine
Note: Elevator Speed information is not shown for CLAAS Quantimeter configurations.
D
IAGNOSTICS FOR

Diagnostics Screen for CLAAS Quantimeter

When performing a Harvest operation, you can access the Grain Harvest Diagnostics
screen by pressing the Display Information button. Technical support may request that you
look at this screen for help in diagnosing a problem. When the Devices screen opens, press
and highlight the AL Bridge listing in the CAN Device list, then press the Diagnostics button. The Grain
Harvest Diagnostics screen appears.
350
CLAAS Q
UANTIMETER
Swath: 30 ft 0 in
Flow
Full Swath
Header
Engine Speed
Fuel
CLAAS Q
UANTIMETER
Once an operating configuration is
5.0
mph
created for a CLAAS Quantimeter
Soybeans
harvest configuration, and a field
Yield
118.6
bu/ac
operation configuration is created at the
Moisture
Home screen, you can view map screen
15.9
%
Area
data.
1.06
ac
Wet Weight
For the most part, this map screen is
6797
lb
similar in appearance to the map screen
Dry Bushels
111 used in other Harvest configurations.
bu
However, the Harvest Diagnostic button,
shown at the bottom right-hand side of
the Equipment Tab (A), differs in
100%
appearance from that shown on other
2205 bu/h
25%
Harvest configuration map screens. This
1115 rpm
Harvest Diagnostic button does not
3 gal/h
display a picture of a combine.
Firmware Version 6.0
