Rate Control Settings - Ag Leader Integra Display Operator's Manual

• (B) Target Rate
• (C) Actual Rate
Two items, Target Rate and Actual Rate, appear on each Product Tab shown in the Product Control
Toolbox. The Target Rate is the desired planting rate. The Actual Rate is communicated by the shaft
rotation sensor.
Note: In some conditions, the Actual Rate may increment slower than the Target Rate, or its numeric values
may vary before matching the Target Rate.
• (D) Manual Valve Control
The Manual Valve Control button allows operators to specify the position of the control
valve. Operators use this option to clean out equipment at the end of the day.
• (E) Prescription button
For more information, see
• (F) Rate 1 button
• (G) Rate 2 button
These only appear on Hydraulic Drive or Stepper Seed Meter configurations. The
Rate 1 and Rate 2 settings represent preset planting rates that allow operators to quickly change
between desired planting rates for each individual product. The active rate button appears with a gray
background behind it. In the example above, Rate 1 is active.
• (H) Rate Increase arrow
• (I) Rate Decrease arrow
Pressing once on
Control Settings screen.
• (J) Rate Setup button
The Rate Setup button opens the Rate Control Settings screen, described at
Settings" on page 182
R C
ATE ONTROL
Press to adjust the Rate 1 and Rate 2 settings shown at the Product Control Toolbox on the
Map screen, as well as import planting prescriptions. To access the Rate Control Settings
screen, press the Rate Setup button on the Product Control Toolbox.
182
"Loading Prescriptions" on page 183
/ increments the rate according to the user-defined amount on the Rate
.
S
ETTINGS
.
"Rate Control
Firmware Version 6.0
