38.4
ac
NH3
Coverage
Coverage
Overlap
Notes:
If a switch is selected as a Left or Right Fence Row Nozzle, the system sends power out of Boom Pin 11
for the left fence row, and Boom Pin 12 for the right fence row.
The boom sections next to the fence row nozzles must be turned on before the fence row nozzle can be
turned on.
L C
OAD ONFIGURATION
screen.
For more information, see
R C
UN ONFIGURATION
Once a configuration has been completed, the Map View button appears at the bottom of the
Home screen. Press the Map View button to see the Map screen. The map below is displayed
in Zoom to Detail view.
238
N lb/ac
150
150
Select Event
"Setup Event" on page 45
15.0
mph
1 After specifying Fence Row Nozzle
150
settings at the Auxiliary Input Assignment
2
130 screen, the Fence Row Nozzle
Indicators (A), which are shaped like
triangles, appear on either side of the
sections behind the vehicle icon.
544.8 lb/min
Flow:
630 gal
Container:
80 ft 100%
Pressure (PSI)
Main: 41
Agitation: 43
Auxiliary:
47
Press: Select Event button.
Select a Season, Grower, Farm, and
Field on the Management Selection
.
