Liquid Rate Control; Create Configuration - Ag Leader Integra Display Operator's Manual

A
PPLICATION
A
PPLICATION
L
IQUID
DirectCommand allows the variable rate application of single or multiple liquid products. Follow the
procedure below to create an operating configuration.
C C
REATE ONFIGURATION
Press: Home button > Setup (wrench) button > Configuration (tractor) button > Configuration tab > Add
(+) button > Application button
1. Select Vehicle
Use drop-down menu to choose a vehicle, or press
continue.
If selecting Self-Propelled Sprayer from the drop-down menu skip steps 2 and 4.
Note:
2. Select Implement
Select an implement from the drop-down list menu, or press
to continue.
3. Enter Implement Make and Model
Press to enter Make and Model name. Press
4. Select Implement Attachment Type
Use the drop-down list to select an implement attachment method. Press
5. Enter Hitch to Implement Axle Distance
Press to enter the hitch to implement axle distance. Press
6. Add Sprayer Functionality
Liquid
Press to add sprayer functionality to the implement.
Application
7. Select Controller
Use the drop-down menu to select a controller or press
continue.
8. Assign Container Name
Container names default to Main Tank. Press
Ag Leader PN 4002083 Rev. N
R C
ATE
Configuration
ONTROL
to enter a new vehicle. Press
to create a new implement. Press
to continue.
to add a controller. Press
to enter a new name if desired.
A
PPLICATION
Application
to continue.
to accept.
to
to
223
