A O
NTENNA FFSETS TAB
At the Antenna Tab, enter the distance from locations on the vehicle to the antenna.
• Measure and enter the horizontal distance from the rear axle to the position of the GPS antenna. Select
IN FRONT or BEHIND to indicate the position of the antenna in relation to the rear axle.
• Measure and enter the horizontal distance from the centerline of the vehicle to the position of the GPS
antenna. Select LEFT or RIGHT to indicate the position from the vehicle centerline.
• Measure and enter the vertical height of the antenna above the ground.
Note: Accuracy when measuring for a specific setting is essential to ensure proper machine performance.
H T S
ITCH AB ETTINGS TAB
The Hitch Tab allows you to enter in the distance from four different mounting positions on the tractor to
the rear axle. Press
Note: Accuracy when measuring for a specific setting is essential to ensure proper machine performance.
M T S
OUNT AB
The Mount Tab will only be available when using a self-propelled application sprayer or spreader. This
allows you to enter in the application location from the rear axle. Press
and the drop-down box to select if it is in front or behind of the axle.
H T (
EAD AB FOR
The Head Tab allows you to enter in the distance from the head attachment point to the rear axle. Press
to enter the distance to the axle.
S S
WATH ECTION
Offsets
Press: Home button > Setup (wrench) button > Configuration (tractor) button > Configuration tab > select
your specific configuration > Setup (wrench) button > Offsets button
The Implement Offsets screen opens. Depending upon your configuration, this screen may consist of up
to two tabs: the Section Offsets Tab and the Hitch Offsets Tab.
86
to enter these values in if using the hitch point.
(
ETTINGS FOR SOME
H
ARVEST VEHICLES
O
FFSETS
A
PPLICATION VEHICLES
)
Select Your Specific
Configuration
Configuration
)
to enter in the distance
Firmware Version 6.0
