Edit Headlands
Edit Headlands
1
Clear All
Headland Alarm Settings
Headland Alarm Settings
Alarm Distance
150
Audible Alarms
Approaching Headland
Crossing Headland Boundary
0.67
ac
traigh
Reset
Nudge: 30.0 in
Total: 0.0 in
Ag Leader PN 4002083 Rev. N
Alarm Duration
10 s
4.5
Pass: 2 R
Headland: 113 ft
Press Edit Headlands button.
Select a headland from list.
• Press
to add a driven headland.
• Press
to delete selected headland.
• Press
to delete all driven headlands.
• Press
to return to Headland Options screen.
• Press
to load selected headland.
This screen will vary depending on type of headland.
Press Headland Alarm Settings button.
Alert Distance - distance from approaching
headland at which display will warn user of
upcoming headland
Alert Duration - time length from approaching
headland at which display will warn user of
upcoming headland
Audible Alarms
• Approaching Headland
• Crossing Headland Boundary
mph
Corn1
Map Screen with Headlands
Corn2
S
ETUP
59
