Seed Monitor Diagnostics; Seed Monitor Alarms - Ag Leader Integra Display Operator's Manual

S M
EED ONITOR
Settings
Press: Map button > Settings button > Seed Monitor tab > Diagnostics button

Seed Monitor Diagnostics

Seed Sensors
sds/sec
1 13
2 13
3 13
4 13
5 13
6 13
7 13
8 13
9 13
10 13
11 13
12 13
Note: This can also be accessed on the CAN device list under Diagnostics.
S M
EED ONITOR
Settings
Press: Map button > Settings button > Seed Monitor tab > Population Alarms

Seed Monitor Alarms

Low
Row High
1 70% 120%
2 70% 120%
3 70% 120%
4 70% 120%
5 70% 120%
6 70% 120%
7 70% 120%
8 70% 120%
9 70% 120%
10 70% 120%
11 70% 120%
High and Low buttons assign a percentage of error that will trigger the rate alarm.
• The Disable High and Disable Low buttons deactivate the respective high or low rate alarms.
• The Select All button selects all rows to change the alarm threshold for the entire group.
Ag Leader PN 4002083 Rev. N
D
IAGNOSTICS
Seed Monitor
sds/ha
sds/ha
79040
79040
79040
79040
79040
79040
79040
79040
79040
79040
79040
79040
A
LARMS
Seed Monitor
High
Low
Disable
High
Disable
Low
Select
All
Diagnostics
The Seed Monitor Diagnostics screen shows row
data from rows monitored by the Seed Tube Monitor
Module, including the following:
• Row unit seeds per second
• Row unit seeds per acre
Population
Alarms
Adjust Seed Tube Monitor Module alarm thresholds.
This screen can be accessed in one of two ways:
- Pressing the Alarms button at the Seed Monitor Option
screen.
- Pressing the Alarms button at the Seed Monitor Setup
screen.
P
LANTING
199
