Direct Injection: Pump Doesn't Run

Boom indicators
turn blue on run
Yes
Verify a value is
entered for the
active calibration
Yes
Verify a target rate is
entered for the injection
control channel
Check power connections
from the battery to the
injection pump
272
See "Boom sections
not turning blue" in
No
manual
Refer to "calibrating
injection pump"
No
Power can be checked at multiple
locations. First is the connection at the
Injection module where the battery
power cable plugs in. The second
location is the output connection found
on the injection module. The third is
found at the 2 pin weather-pak tower
found on the injection cable PN:
4000851-3. See table below.
Firmware Version 6.0
