Planting Map Screen - Zoom Detail; Legend Select - Ag Leader Integra Display Operator's Manual

P M
LANTING AP
38.4
ac
Corn
Varieties
C1966
C1291
Population: 32000 sds/ac
120 %
100 %
Planter Drives (rpm)
80 %
60 %
3
37
2
When the Map screen is shown in Zoom Detail, the Vehicle Icon appears as a gold triangle, rather than
an arrow.
L S
EGEND ELECT
During Planting operations, the Map screen displays two types of items in the Legend: Coverage and
Varieties. The Variety Legend is only accessible in the Zoom to Extent view.
The Legend Setup button on the Map Legend Tab of the Mapping Toolbox opens the
Legend Select screen.

Legend Select

92M54
Varieties
Coverage
Load
Clear Map
Reference
Settings" on page 52
• Press Clear Map to permanently remove all logged data from the active field operation.
• Press Load Reference to load a list of maps of previous operations performed in that field.
202
S - Z
CREEN OOM
Spacing: 6.7 in
8 10 14 20 22
4 6 12 16 18
.
D
ETAIL
5.0
mph
C1291
• (A) GPS Status
3200
32000
• (B) Total Field Acres
C1291
sds/ac
36000
• (C) On-screen Lightbar
36000
• (D) Ground Speed
• (E) Diagnostics button
• (F) Productivity tab (Variety)
• (G) Logging Status button
• (H) AutoSwath
Settings
• (I) Map View button
Down Force
Gauge Wheel: 197 lb
• (J) Home button
Down Force: 197 lb
1
24
• (K) Map Legend (Coverage)
Use the drop-down menu at the top to select product.
Choose from the following items:
• Press Coverage to show the area already planted.
• Press Varieties to show a Variety Map of the field which
shows where specific varieties are planted. The colors
shown on the Variety Map can be edited. For more
information, see
"Legend Setup"
• For SeedCommand (rate control) configuration, press
Rate to show the Rate Legend in the Mapping Toolbox.
The rate map displays the actual rate being applied. This
legend is editable. For more information, see
below.
"Legend
Firmware Version 6.0
